Table 15-7. ADC Register Map (continued)
See
page
DescriptionResetTypeNameOffset
1096ADC Underflow Status0x0000.0000RW1CADCUSTAT0x018
1097ADC Trigger Source Select0x0000.0000RWADCTSSEL0x01C
1099ADC Sample Sequencer Priority0x0000.3210RWADCSSPRI0x020
1101ADC Sample Phase Control0x0000.0000RWADCSPC0x024
1103ADC Processor Sample Sequence Initiate-RWADCPSSI0x028
1105ADC Sample Averaging Control0x0000.0000RWADCSAC0x030
1106ADC Digital Comparator Interrupt Status and Clear0x0000.0000RW1CADCDCISC0x034
1108ADC Control0x0000.0000RWADCCTL0x038
1109ADC Sample Sequence Input Multiplexer Select 00x0000.0000RWADCSSMUX00x040
1111ADC Sample Sequence Control 00x0000.0000RWADCSSCTL00x044
1118ADC Sample Sequence Result FIFO 0-ROADCSSFIFO00x048
1119ADC Sample Sequence FIFO 0 Status0x0000.0100ROADCSSFSTAT00x04C
1121ADC Sample Sequence 0 Operation0x0000.0000RWADCSSOP00x050
1123ADC Sample Sequence 0 Digital Comparator Select0x0000.0000RWADCSSDC00x054
1125
ADC Sample Sequence Extended Input Multiplexer Select
0
0x0000.0000RWADCSSEMUX00x058
1127ADC Sample Sequence 0 Sample and Hold Time0x0000.0000RWADCSSTSH00x05C
1129ADC Sample Sequence Input Multiplexer Select 10x0000.0000RWADCSSMUX10x060
1130ADC Sample Sequence Control 10x0000.0000RWADCSSCTL10x064
1118ADC Sample Sequence Result FIFO 1-ROADCSSFIFO10x068
1119ADC Sample Sequence FIFO 1 Status0x0000.0100ROADCSSFSTAT10x06C
1134ADC Sample Sequence 1 Operation0x0000.0000RWADCSSOP10x070
1135ADC Sample Sequence 1 Digital Comparator Select0x0000.0000RWADCSSDC10x074
1137
ADC Sample Sequence Extended Input Multiplexer Select
1
0x0000.0000RWADCSSEMUX10x078
1139ADC Sample Sequence 1 Sample and Hold Time0x0000.0000RWADCSSTSH10x07C
1129ADC Sample Sequence Input Multiplexer Select 20x0000.0000RWADCSSMUX20x080
1130ADC Sample Sequence Control 20x0000.0000RWADCSSCTL20x084
1118ADC Sample Sequence Result FIFO 2-ROADCSSFIFO20x088
1119ADC Sample Sequence FIFO 2 Status0x0000.0100ROADCSSFSTAT20x08C
1134ADC Sample Sequence 2 Operation0x0000.0000RWADCSSOP20x090
1135ADC Sample Sequence 2 Digital Comparator Select0x0000.0000RWADCSSDC20x094
June 18, 20141074
Texas Instruments-Production Data
Analog-to-Digital Converter (ADC)
