Table 26-4. Signals by Function, Except for GPIO (continued)
DescriptionBuffer TypePin TypePin NumberPin NameFunction
UART module 4 Clear To Send modem flow control
input signal.
UART module 4 Request to Send modem flow
control output line.
TTLO20U4RTS
UART module 4 receive.TTLI18
35
U4Rx
UART module 4 transmit.TTLO19
36
U4Tx
UART module 5 receive.TTLI23U5Rx
UART module 5 transmit.TTLO22U5Tx
UART module 6 receive.TTLI118U6Rx
UART module 6 transmit.TTLO119U6Tx
UART module 7 receive.TTLI25U7Rx
UART module 7 transmit.TTLO24U7Tx
60-MHz clock to the external PHY.TTLO92USB0CLK
USB
USB data 0.TTLI/O81USB0D0
USB data 1.TTLI/O82USB0D1
USB data 2.TTLI/O83USB0D2
USB data 3.TTLI/O84USB0D3
USB data 4.TTLI/O85USB0D4
USB data 5.TTLI/O86USB0D5
USB data 6.TTLI/O106USB0D6
USB data 7.TTLI/O105USB0D7
Indicates that the external PHY is able to accept
data from the USB controller.
TTLO104USB0DIR
Bidirectional differential data pin (D- per USB
specification) for USB0.
AnalogI/O93USB0DM
Bidirectional differential data pin (D+ per USB
specification) for USB0.
AnalogI/O94USB0DP
Optionally used in Host mode to control an external
power source to supply power to the USB bus.
TTLO40
41
127
USB0EPEN
This signal senses the state of the USB ID signal.
The USB PHY enables an integrated pull-up, and
an external element (USB connector) indicates the
initial state of the USB controller (pulled down is
the A side of the cable and pulled up is the B side).
AnalogI95USB0ID
Asserted by the external PHY to throttle all data
types.
TTLO103USB0NXT
Optionally used in Host mode by an external power
source to indicate an error state by that power
source.
TTLI41
128
USB0PFLT
Asserted by the USB controller to signal the end of
a USB transmit packet or register write operation.
TTLO91USB0STP
This signal is used during the session request
protocol. This signal allows the USB PHY to both
sense the voltage level of VBUS, and pull up VBUS
momentarily during VBUS pulsing.
AnalogI/O96USB0VBUS
1807June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
