Table 27-60. Analog Comparator Voltage Reference Characteristics, V
DDA
= 3.3V, EN= 1, and
RNG = 0 (continued)
UnitV
IREF
MaxIdeal V
IREF
V
IREF
MinVREF Value
V2.3002.2452.1900xD
V2.4122.3572.3020xE
V2.5252.4692.4140xF
Table 27-61. Analog Comparator Voltage Reference Characteristics, V
DDA
= 3.3V, EN= 1, and
RNG = 1
UnitV
IREF
MaxIdeal V
IREF
V
IREF
MinVREF Value
V0.0740.0000.0000x0
V0.2230.1490.0760x1
V0.3720.2980.2250x2
V0.5210.4480.3740x3
V0.6700.5970.5230x4
V0.8200.7460.6720x5
V0.9690.8950.8220x6
V1.1181.0440.9710x7
V1.2671.1931.1200x8
V1.4161.3431.2690x9
V1.5651.4921.4180xA
V1.7151.6411.5670xB
V1.8641.7901.7170xC
V2.0131.9391.8660xD
V2.1622.0892.0150xE
V2.3112.2382.1640xF
