GPIO Pull-Up Select (GPIOPUR)
GPIO Port A (AHB) base: 0x4005.8000
GPIO Port B (AHB) base: 0x4005.9000
GPIO Port C (AHB) base: 0x4005.A000
GPIO Port D (AHB) base: 0x4005.B000
GPIO Port E (AHB) base: 0x4005.C000
GPIO Port F (AHB) base: 0x4005.D000
GPIO Port G (AHB) base: 0x4005.E000
GPIO Port H (AHB) base: 0x4005.F000
GPIO Port J (AHB) base: 0x4006.0000
GPIO Port K (AHB) base: 0x4006.1000
GPIO Port L (AHB) base: 0x4006.2000
GPIO Port M (AHB) base: 0x4006.3000
GPIO Port N (AHB) base: 0x4006.4000
GPIO Port P (AHB) base: 0x4006.5000
GPIO Port Q (AHB) base: 0x4006.6000
Offset 0x510
Type RW, reset -
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
PUEreserved
RWRWRWRWRWRWRWRWROROROROROROROROType
--------00000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.00ROreserved31:8
Pad Weak Pull-Up Enable
DescriptionValue
The corresponding pin's weak pull-up resistor is disabled.0
The corresponding pin's weak pull-up resistor is enabled.1
Setting a bit in the GPIOPDR register clears the corresponding bit in
the GPIOPUR register. The change is effective on the next clock cycle.
The reset value for this register is 0x0000.0000 for GPIO ports that are
not listed in Table 10-1 on page 743.
-RWPUE7:0
777June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
