Texas Instruments TM4C1294NCPDT User Manual

Table 20-23. Ethernet Register Map (continued)
See
page
DescriptionResetTypeNameOffset
1544Ethernet MAC Target Time Seconds0x0000.0000RWEMACTARGSEC0x71C
1545Ethernet MAC Target Time Nanoseconds0x0000.0000RWEMACTARGNANO0x720
1546Ethernet MAC System Time-Higher Word Seconds0x0000.0000RWEMACHWORDSEC0x724
1547Ethernet MAC Timestamp Status0x0000.0000ROEMACTIMSTAT0x728
1548Ethernet MAC PPS Control0x0000.0000RWEMACPPSCTRL0x72C
1551Ethernet MAC PPS0 Interval0x0000.0000RWEMACPPS0INTVL0x760
1552Ethernet MAC PPS0 Width0x0000.0000RWEMACPPS0WIDTH0x764
1553Ethernet MAC DMA Bus Mode0x0002.0101RWEMACDMABUSMOD0xC00
1557Ethernet MAC Transmit Poll Demand0x0000.0000WOEMACTXPOLLD0xC04
1558Ethernet MAC Receive Poll Demand0x0000.0000WOEMACRXPOLLD0xC08
1559Ethernet MAC Receive Descriptor List Address0x0000.0000RWEMACRXDLADDR0xC0C
1560Ethernet MAC Transmit Descriptor List Address0x0000.0000RWEMACTXDLADDR0xC10
1561Ethernet MAC DMA Interrupt Status0x0000.0000RWEMACDMARIS0xC14
1567Ethernet MAC DMA Operation Mode0x0000.0000RWEMACDMAOPMODE0xC18
1572Ethernet MAC DMA Interrupt Mask Register0x0000.0000RWEMACDMAIM0xC1C
1575
Ethernet MAC Missed Frame and Buffer Overflow
Counter
0x0000.0000ROEMACMFBOC0xC20
1576Ethernet MAC Receive Interrupt Watchdog Timer0x0000.0000RWEMACRXINTWDT0xC24
1577Ethernet MAC Current Host Transmit Descriptor0x0000.0000REMACHOSTXDESC0xC48
1578Ethernet MAC Current Host Receive Descriptor0x0000.0000ROEMACHOSRXDESC0xC4C
1579Ethernet MAC Current Host Transmit Buffer Address0x0000.0000REMACHOSTXBA0xC50
1580Ethernet MAC Current Host Receive Buffer Address0x0000.0000REMACHOSRXBA0xC54
1581Ethernet MAC Peripheral Property Register0x0000.0103ROEMACPP0xFC0
1582Ethernet MAC Peripheral Configuration Register0x0080.040ERWEMACPC0xFC4
1586Ethernet MAC Clock Configuration Register0x0000.0000ROEMACCC0xFC8
1587Ethernet PHY Raw Interrupt Status0x0000.0000ROEPHYRIS0xFD0
1588Ethernet PHY Interrupt Mask0x0000.0000RWEPHYIM0xFD4
1589Ethernet PHY Masked Interrupt Status and Clear0x0000.0000RW1CEPHYMISC0xFD8
MII Management (Accessed through the EMACMIIADDR Register)
1590Ethernet PHY Basic Mode Control - MR00x3100RWEPHYBMCR-
1592Ethernet PHY Basic Mode Status - MR10x7849ROEPHYBMSR-
1595Ethernet PHY Identifier Register 1 - MR20x2000REPHYID1-
1469June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
