Texas Instruments TM4C1294NCPDT User Manual

Table 20-23. Ethernet Register Map (continued)
See
page
DescriptionResetTypeNameOffset
1504Ethernet MAC Address 1 Low0xFFFF.FFFFRWEMACADDR1L0x04C
1505Ethernet MAC Address 2 High0x0000.FFFFRWEMACADDR2H0x050
1507Ethernet MAC Address 2 Low0xFFFF.FFFFRWEMACADDR2L0x054
1508Ethernet MAC Address 3 High0x0000.FFFFRWEMACADDR3H0x058
1510Ethernet MAC Address 3 Low0xFFFF.FFFFRWEMACADDR3L0x05C
1511Ethernet MAC Watchdog Timeout0x0000.0000RWEMACWDOGTO0x0DC
1512Ethernet MAC MMC Control0x0000.0000RWEMACMMCCTRL0x100
1515Ethernet MAC MMC Receive Raw Interrupt Status0x0000.0000ROEMACMMCRXRIS0x104
1517Ethernet MAC MMC Transmit Raw Interrupt Status0x0000.0000REMACMMCTXRIS0x108
1519Ethernet MAC MMC Receive Interrupt Mask0x0000.0000RWEMACMMCRXIM0x10C
1521Ethernet MAC MMC Transmit Interrupt Mask0x0000.0000RWEMACMMCTXIM0x110
1523
Ethernet MAC Transmit Frame Count for Good and Bad
Frames
0x0000.0000ROEMACTXCNTGB0x118
1524
Ethernet MAC Transmit Frame Count for Frames
Transmitted after Single Collision
0x0000.0000ROEMACTXCNTSCOL0x14C
1525
Ethernet MAC Transmit Frame Count for Frames
Transmitted after Multiple Collisions
0x0000.0000ROEMACTXCNTMCOL0x150
1526Ethernet MAC Transmit Octet Count Good0x0000.0000ROEMACTXOCTCNTG0x164
1527
Ethernet MAC Receive Frame Count for Good and Bad
Frames
0x0000.0000ROEMACRXCNTGB0x180
1528
Ethernet MAC Receive Frame Count for CRC Error
Frames
0x0000.0000ROEMACRXCNTCRCERR0x194
1529
Ethernet MAC Receive Frame Count for Alignment Error
Frames
0x0000.0000ROEMACRXCNTALGNERR0x198
1530
Ethernet MAC Receive Frame Count for Good Unicast
Frames
0x0000.0000ROEMACRXCNTGUNI0x1C4
1531Ethernet MAC VLAN Tag Inclusion or Replacement0x0000.0000RWEMACVLNINCREP0x584
1533Ethernet MAC VLAN Hash Table0x0000.0000RWEMACVLANHASH0x588
1534Ethernet MAC Timestamp Control0x0000.2000RWEMACTIMSTCTRL0x700
1538Ethernet MAC Sub-Second Increment0x0000.0000RWEMACSUBSECINC0x704
1539Ethernet MAC System Time - Seconds0x0000.0000ROEMACTIMSEC0x708
1540Ethernet MAC System Time - Nanoseconds0x0000.0000ROEMACTIMNANO0x70C
1541Ethernet MAC System Time - Seconds Update0x0000.0000RWEMACTIMSECU0x710
1542Ethernet MAC System Time - Nanoseconds Update0x0000.0000RWEMACTIMNANOU0x714
1543Ethernet MAC Timestamp Addend0x0000.0000RWEMACTIMADD0x718
June 18, 20141468
Texas Instruments-Production Data
Ethernet Controller
