Table 26-2. Signals by Pin Number (continued)
DescriptionBuffer TypePin TypePin NamePin Number
GPIO port F bit 4.TTLI/OPF4
46
Ethernet 0 LED 1.TTLOEN0LED1
Motion Control Module 0 PWM Fault 0.TTLIM0FAULT0
SSI Module 3 Bi-directional Data Pin 2.TTLI/OSSI3XDAT2
Trace data 3.TTLOTRD3
Positive supply for I/O and some logic.Power-VDD
47
Ground reference for logic and I/O pins.Power-GND
48
GPIO port G bit 0.TTLI/OPG0
49
Ethernet 0 Pulse-Per-Second (PPS) Output.TTLOEN0PPS
EPI module 0 signal 11.TTLI/OEPI0S11
I
2
C module 1 clock. Note that this signal has an active pull-up. The
corresponding port pin should not be configured as open drain.
ODI/OI2C1SCL
Motion Control Module 0 PWM 4. This signal is controlled by
Module 0 PWM Generator 2.
TTLOM0PWM4
GPIO port G bit 1.TTLI/OPG1
50
EPI module 0 signal 10.TTLI/OEPI0S10
I
2
C module 1 data.ODI/OI2C1SDA
Motion Control Module 0 PWM 5. This signal is controlled by
Module 0 PWM Generator 2.
TTLOM0PWM5
Positive supply for I/O and some logic.Power-VDD
51
Positive supply for I/O and some logic.Power-VDD
52
Ethernet PHY negative receive differential input.TTLI/OEN0RXIN
53
Ethernet PHY positive receive differential input.TTLI/OEN0RXIP
54
Ground reference for logic and I/O pins.Power-GND
55
Ethernet PHY negative transmit differential output.TTLI/OEN0TXON
56
Ethernet PHY positive transmit differential output.TTLI/OEN0TXOP
57
Ground reference for logic and I/O pins.Power-GND
58
4.87-kΩ resistor (1% precision) for Ethernet PHY.AnalogORBIAS
59
GPIO port K bit 7.TTLI/OPK7
60
EPI module 0 signal 24.TTLI/OEPI0S24
I
2
C module 4 data.ODI/OI2C4SDA
Motion Control Module 0 PWM Fault 2.TTLIM0FAULT2
Buffered version of the Hibernation module's 32.768-kHz clock.
This signal is not output when the part is in Hibernate mode and
before being configured after power-on reset.
TTLORTCCLK
UART module 0 Ring Indicator modem status input signal.TTLIU0RI
GPIO port K bit 6.TTLI/OPK6
61
Ethernet 0 LED 1.TTLOEN0LED1
EPI module 0 signal 25.TTLI/OEPI0S25
I
2
C module 4 clock. Note that this signal has an active pull-up. The
corresponding port pin should not be configured as open drain.
ODI/OI2C4SCL
Motion Control Module 0 PWM Fault 1.TTLIM0FAULT1
June 18, 20141778
Texas Instruments-Production Data
