Table 26-2. Signals by Pin Number (continued)
DescriptionBuffer TypePin TypePin NamePin Number
GPIO port P bit 0.TTLI/OPP0
118
Analog comparator 2 positive input.AnalogIC2+
SSI Module 3 Bi-directional Data Pin 2.TTLI/OSSI3XDAT2
UART module 6 receive.TTLIU6Rx
GPIO port P bit 1.TTLI/OPP1
119
Analog comparator 2 negative input.AnalogIC2-
SSI Module 3 Bi-directional Data Pin 3.TTLI/OSSI3XDAT3
UART module 6 transmit.TTLOU6Tx
GPIO port B bit 5.TTLI/OPB5
120
Analog-to-digital converter input 11.AnalogIAIN11
I
2
C module 5 data.ODI/OI2C5SDA
SSI module 1 clock.TTLI/OSSI1Clk
UART module 0 Request to Send modem flow control output signal.TTLOU0RTS
GPIO port B bit 4.TTLI/OPB4
121
Analog-to-digital converter input 10.AnalogIAIN10
I
2
C module 5 clock. Note that this signal has an active pull-up. The
corresponding port pin should not be configured as open drain.
ODI/OI2C5SCL
SSI module 1 frame signal.TTLI/OSSI1Fss
UART module 0 Clear To Send modem flow control input signal.TTLIU0CTS
Positive supply for I/O and some logic.Power-VDD
122
GPIO port E bit 4.TTLI/OPE4
123
Analog-to-digital converter input 9.AnalogIAIN9
SSI Module 1 Bi-directional Data Pin 0 (SSI1TX in Legacy SSI
Mode).
TTLI/OSSI1XDAT0
UART module 1 Ring Indicator modem status input signal.TTLIU1RI
GPIO port E bit 5.TTLI/OPE5
124
Analog-to-digital converter input 8.AnalogIAIN8
SSI Module 1 Bi-directional Data Pin 1 (SSI1RX in Legacy SSI
Mode).
TTLI/OSSI1XDAT1
GPIO port D bit 4.TTLI/OPD4
125
Analog-to-digital converter input 7.AnalogIAIN7
SSI Module 1 Bi-directional Data Pin 2.TTLI/OSSI1XDAT2
16/32-Bit Timer 3 Capture/Compare/PWM 0.TTLI/OT3CCP0
UART module 2 receive.TTLIU2Rx
GPIO port D bit 5.TTLI/OPD5
126
Analog-to-digital converter input 6.AnalogIAIN6
SSI Module 1 Bi-directional Data Pin 3.TTLI/OSSI1XDAT3
16/32-Bit Timer 3 Capture/Compare/PWM 1.TTLI/OT3CCP1
UART module 2 transmit.TTLOU2Tx
June 18, 20141784
Texas Instruments-Production Data
Signal Tables
To Next Page
