Table 26-3. Signals by Signal Name (continued)
DescriptionBuffer TypePin TypePin Mux / Pin
Assignment
Pin NumberPin Name
Analog comparator 0 negative input.AnalogIPC722C0-
Analog comparator 0 output.TTLOPD0 (5)
PL2 (5)
1
83
C0o
Analog comparator 1 positive input.AnalogIPC524C1+
Analog comparator 1 negative input.AnalogIPC425C1-
Analog comparator 1 output.TTLOPD1 (5)
PL3 (5)
2
84
C1o
Analog comparator 2 positive input.AnalogIPP0118C2+
Analog comparator 2 negative input.AnalogIPP1119C2-
Analog comparator 2 output.TTLOPD2 (5)3C2o
CAN module 0 receive.TTLIPA0 (7)33CAN0Rx
CAN module 0 transmit.TTLOPA1 (7)34CAN0Tx
CAN module 1 receive.TTLIPB0 (7)95CAN1Rx
CAN module 1 transmit.TTLOPB1 (7)96CAN1Tx
An optionally divided reference clock output based
on a selected clock source. Note that this signal is
not synchronized to the System Clock.
TTLOPQ4 (7)102DIVSCLK
Ethernet 0 LED 0.TTLOPF0 (5)
PK4 (5)
42
63
EN0LED0
Ethernet 0 LED 1.TTLOPF4 (5)
PK6 (5)
46
61
EN0LED1
Ethernet 0 LED 2.TTLOPF1 (5)
PK5 (5)
43
62
EN0LED2
Ethernet 0 Pulse-Per-Second (PPS) Output.TTLOPG0 (5)
PJ0 (5)
49
116
EN0PPS
Ethernet PHY negative receive differential input.TTLI/Ofixed53EN0RXIN
Ethernet PHY positive receive differential input.TTLI/Ofixed54EN0RXIP
Ethernet PHY negative transmit differential output.TTLI/Ofixed56EN0TXON
Ethernet PHY positive transmit differential output.TTLI/Ofixed57EN0TXOP
EPI module 0 signal 0.TTLI/OPK0 (15)
PH0 (15)
18
29
EPI0S0
EPI module 0 signal 1.TTLI/OPK1 (15)
PH1 (15)
19
30
EPI0S1
EPI module 0 signal 2.TTLI/OPK2 (15)
PH2 (15)
20
31
EPI0S2
EPI module 0 signal 3.TTLI/OPK3 (15)
PH3 (15)
21
32
EPI0S3
EPI module 0 signal 4.TTLI/OPC7 (15)22EPI0S4
EPI module 0 signal 5.TTLI/OPC6 (15)23EPI0S5
EPI module 0 signal 6.TTLI/OPC5 (15)24EPI0S6
EPI module 0 signal 7.TTLI/OPC4 (15)25EPI0S7
EPI module 0 signal 8.TTLI/OPA6 (15)40EPI0S8
EPI module 0 signal 9.TTLI/OPA7 (15)41EPI0S9
EPI module 0 signal 10.TTLI/OPG1 (15)50EPI0S10
