Table 26-4. Signals by Function, Except for GPIO (continued)
DescriptionBuffer TypePin TypePin NumberPin NameFunction
JTAG/SWD CLK.TTLI100SWCLK
JTAG/SWD/SWO
JTAG TMS and SWDIO.TTLI/O99SWDIO
JTAG TDO and SWO.TTLO97SWO
JTAG/SWD CLK.TTLI100TCK
JTAG TDI.TTLI98TDI
JTAG TDO and SWO.TTLO97TDO
JTAG TMS and SWDIO.TTLI99TMS
Motion Control Module 0 PWM Fault 0.TTLI46M0FAULT0
PWM
Motion Control Module 0 PWM Fault 1.TTLI61M0FAULT1
Motion Control Module 0 PWM Fault 2.TTLI60M0FAULT2
Motion Control Module 0 PWM Fault 3.TTLI81M0FAULT3
Motion Control Module 0 PWM 0. This signal is
controlled by Module 0 PWM Generator 0.
TTLO42M0PWM0
Motion Control Module 0 PWM 1. This signal is
controlled by Module 0 PWM Generator 0.
TTLO43M0PWM1
Motion Control Module 0 PWM 2. This signal is
controlled by Module 0 PWM Generator 1.
TTLO44M0PWM2
Motion Control Module 0 PWM 3. This signal is
controlled by Module 0 PWM Generator 1.
TTLO45M0PWM3
Motion Control Module 0 PWM 4. This signal is
controlled by Module 0 PWM Generator 2.
TTLO49M0PWM4
Motion Control Module 0 PWM 5. This signal is
controlled by Module 0 PWM Generator 2.
TTLO50M0PWM5
Motion Control Module 0 PWM 6. This signal is
controlled by Module 0 PWM Generator 3.
TTLO63M0PWM6
Motion Control Module 0 PWM 7. This signal is
controlled by Module 0 PWM Generator 3.
TTLO62M0PWM7
