Table 26-3. Signals by Signal Name (continued)
DescriptionBuffer TypePin TypePin Mux / Pin
Assignment
Pin NumberPin Name
GPIO port D bit 2.TTLI/O-3PD2
GPIO port D bit 3.TTLI/O-4PD3
GPIO port D bit 4.TTLI/O-125PD4
GPIO port D bit 5.TTLI/O-126PD5
GPIO port D bit 6.TTLI/O-127PD6
GPIO port D bit 7.TTLI/O-128PD7
GPIO port E bit 0.TTLI/O-15PE0
GPIO port E bit 1.TTLI/O-14PE1
GPIO port E bit 2.TTLI/O-13PE2
GPIO port E bit 3.TTLI/O-12PE3
GPIO port E bit 4.TTLI/O-123PE4
GPIO port E bit 5.TTLI/O-124PE5
GPIO port F bit 0.TTLI/O-42PF0
GPIO port F bit 1.TTLI/O-43PF1
GPIO port F bit 2.TTLI/O-44PF2
GPIO port F bit 3.TTLI/O-45PF3
GPIO port F bit 4.TTLI/O-46PF4
GPIO port G bit 0.TTLI/O-49PG0
GPIO port G bit 1.TTLI/O-50PG1
GPIO port H bit 0.TTLI/O-29PH0
GPIO port H bit 1.TTLI/O-30PH1
GPIO port H bit 2.TTLI/O-31PH2
GPIO port H bit 3.TTLI/O-32PH3
QEI module 0 phase A.TTLIPL1 (6)82PhA0
QEI module 0 phase B.TTLIPL2 (6)83PhB0
GPIO port J bit 0.TTLI/O-116PJ0
GPIO port J bit 1.TTLI/O-117PJ1
GPIO port K bit 0.TTLI/O-18PK0
GPIO port K bit 1.TTLI/O-19PK1
GPIO port K bit 2.TTLI/O-20PK2
GPIO port K bit 3.TTLI/O-21PK3
GPIO port K bit 4.TTLI/O-63PK4
GPIO port K bit 5.TTLI/O-62PK5
GPIO port K bit 6.TTLI/O-61PK6
GPIO port K bit 7.TTLI/O-60PK7
GPIO port L bit 0.TTLI/O-81PL0
GPIO port L bit 1.TTLI/O-82PL1
GPIO port L bit 2.TTLI/O-83PL2
GPIO port L bit 3.TTLI/O-84PL3
GPIO port L bit 4.TTLI/O-85PL4
GPIO port L bit 5.TTLI/O-86PL5
June 18, 20141790
Texas Instruments-Production Data
