Texas Instruments AFE79 Series User Manual

IO Wrap Register Map www.ti.com
1000
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.16.6 Register 206h (offset = 206h) [reset = 0h]
Figure 2-2269. Register 206h
7 6 5 4 3 2 1 0
ODRIV_DS_GPIO_1
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2285. Register 206 Field Descriptions
Bit Field Type Reset Description
1-0
ODRIV_DS_GPIO_
1
R/W 0h output buffer drive strength.
2.16.7 Register 208h (offset = 208h) [reset = 1h]
Figure 2-2270. Register 208h
7 6 5 4 3 2 1 0
PULL_CTRL_GPIO_2
R/W-1h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2286. Register 208 Field Descriptions
Bit Field Type Reset Description
2-0
PULL_CTRL_GPIO
_2
R/W 1h
Bit 0 indicates Pull up enable.
Bit <1> Indicates Pull value.
Bit <2> is unused.
2.16.8 Register 209h (offset = 209h) [reset = 2h]
Figure 2-2271. Register 209h
7 6 5 4 3 2 1 0
IBUF_ST_GPIO_2
R/W-2h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2287. Register 209 Field Descriptions
Bit Field Type Reset Description
1-0 IBUF_ST_GPIO_2 R/W 2h Input buffer signal strength
2.16.9 Register 20Ah (offset = 20Ah) [reset = 0h]
Figure 2-2272. Register 20Ah
7 6 5 4 3 2 1 0
ODRIV_DS_GPIO_2
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
