2.6.185 Register 7E0Ah (offset = 7E0Ah) [reset = 0h]
Figure 2-899. Register 7E0Ah
7 6 5 4 3 2 1 0
FIRMWARE_DATA5[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-905. Register 7E0A Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
5[7:0]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.186 Register 7E0Bh (offset = 7E0Bh) [reset = 0h]
Figure 2-900. Register 7E0Bh
7 6 5 4 3 2 1 0
FIRMWARE_DATA5[15:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-906. Register 7E0B Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
5[15:8]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.187 Register 7E0Ch (offset = 7E0Ch) [reset = 0h]
Figure 2-901. Register 7E0Ch
7 6 5 4 3 2 1 0
FIRMWARE_DATA6[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-907. Register 7E0C Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
6[7:0]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
