Table 2-1078. Register 12A Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG12[23:16]
R 0h
Macro result register # 12. Interpretation of the contents of this
register depend on the last macro command
2.8.140 Register 12Bh (offset = 12Bh) [reset = 0h]
Figure 2-1071. Register 12Bh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG12[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1079. Register 12B Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG12[31:24]
R 0h
Macro result register # 12. Interpretation of the contents of this
register depend on the last macro command
2.8.141 Register 12Ch (offset = 12Ch) [reset = 0h]
Figure 2-1072. Register 12Ch
7 6 5 4 3 2 1 0
MACRO_RESULT_REG13[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1080. Register 12C Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG13[7:0]
R 0h
Macro result register # 13. Interpretation of the contents of this
register depend on the last macro command
2.8.142 Register 12Dh (offset = 12Dh) [reset = 0h]
Figure 2-1073. Register 12Dh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG13[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1081. Register 12D Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG13[15:8]
R 0h
Macro result register # 13. Interpretation of the contents of this
register depend on the last macro command
