Serial Interface Register Maps
2.8.143 Register 12Eh (offset = 12Eh) [reset = 0h]
Figure 2-1074. Register 12Eh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG13[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1082. Register 12E Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG13[23:16]
R 0h
Macro result register # 13. Interpretation of the contents of this
register depend on the last macro command
2.8.144 Register 12Fh (offset = 12Fh) [reset = 0h]
Figure 2-1075. Register 12Fh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG13[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1083. Register 12F Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG13[31:24]
R 0h
Macro result register # 13. Interpretation of the contents of this
register depend on the last macro command
2.8.145 Register 130h (offset = 130h) [reset = 0h]
Figure 2-1076. Register 130h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG14[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1084. Register 130 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG14[7:0]
R 0h
Macro result register # 14. Interpretation of the contents of this
register depend on the last macro command
2.8.146 Register 131h (offset = 131h) [reset = 0h]
Figure 2-1077. Register 131h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG14[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
