www.ti.com IO Wrap Register Map
1145
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.16.443 Register 854h (offset = 854h) [reset = 0h]
Figure 2-2706. Register 854h
7 6 5 4 3 2 1 0
SEL_INTPI_RXCD_DSA_GAINL
EN
POL_INTPI_RX
CD_DSA_GAIN
LEN
R/W-0h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2722. Register 854 Field Descriptions
Bit Field Type Reset Description
2-1
SEL_INTPI_RXCD
_DSA_GAINLEN
R/W 0h
select control for intpi_rxcd_dsa_gainlen. 0 indicates take from
parallel GPIO 1 indicates take from Serial LVDS GPIO 2
indicates take from Serdes GPIO
0-0
POL_INTPI_RXCD
_DSA_GAINLEN
R/W 0h
polarity control for intpi_rxcd_dsa_gainlen. 0 indicates pass
through from GPIO when selected 1 indicates inverted signal
2.16.444 Register 855h (offset = 855h) [reset = 2h]
Figure 2-2707. Register 855h
7 6 5 4 3 2 1 0
OVR_SEL_INT
PI_RXCD_DSA
_GAINLEN
OVR_INTPI_R
XCD_DSA_GAI
NLEN
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2723. Register 855 Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPI_
RXCD_DSA_GAIN
LEN
R/W 1h
control to select whether the input function
intpi_rxcd_dsa_gainlen needs to be overriden ot not. 1
indicates override.
0-0
OVR_INTPI_RXCD
_DSA_GAINLEN
R/W 0h
override value for ovr_sel_intpi_rxcd_dsa_gainlen is made
high
2.16.445 Register 858h (offset = 858h) [reset = 0h]
Figure 2-2708. Register 858h
7 6 5 4 3 2 1 0
SEL_INTPI_RXA_DSA_GAIN_0 POL_INTPI_RX
A_DSA_GAIN_
0
R/W-0h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2724. Register 858 Field Descriptions
Bit Field Type Reset Description
2-1
SEL_INTPI_RXA_
DSA_GAIN_0
R/W 0h
select control for intpi_rxa_dsa_gain_0. 0 indicates take from
parallel GPIO 1 indicates take from Serial LVDS GPIO 2
indicates take from Serdes GPIO
0-0
POL_INTPI_RXA_
DSA_GAIN_0
R/W 0h
polarity control for intpi_rxa_dsa_gain_0. 0 indicates pass
through from GPIO when selected 1 indicates inverted signal
