Serial Interface Register Maps
Table 2-1085. Register 131 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG14[15:8]
R 0h
Macro result register # 14. Interpretation of the contents of this
register depend on the last macro command
2.8.147 Register 132h (offset = 132h) [reset = 0h]
Figure 2-1078. Register 132h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG14[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1086. Register 132 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG14[23:16]
R 0h
Macro result register # 14. Interpretation of the contents of this
register depend on the last macro command
2.8.148 Register 133h (offset = 133h) [reset = 0h]
Figure 2-1079. Register 133h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG14[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1087. Register 133 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG14[31:24]
R 0h
Macro result register # 14. Interpretation of the contents of this
register depend on the last macro command
2.8.149 Register 134h (offset = 134h) [reset = 0h]
Figure 2-1080. Register 134h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG15[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1088. Register 134 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG15[7:0]
R 0h
Macro result register # 15. Interpretation of the contents of this
register depend on the last macro command
