Serial Interface Register Maps
2.8.136 Register 127h (offset = 127h) [reset = 0h]
Figure 2-1067. Register 127h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG11[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1075. Register 127 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG11[31:24]
R 0h
Macro result register # 11. Interpretation of the contents of this
register depend on the last macro command
2.8.137 Register 128h (offset = 128h) [reset = 0h]
Figure 2-1068. Register 128h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG12[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1076. Register 128 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG12[7:0]
R 0h
Macro result register # 12. Interpretation of the contents of this
register depend on the last macro command
2.8.138 Register 129h (offset = 129h) [reset = 0h]
Figure 2-1069. Register 129h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG12[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1077. Register 129 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG12[15:8]
R 0h
Macro result register # 12. Interpretation of the contents of this
register depend on the last macro command
2.8.139 Register 12Ah (offset = 12Ah) [reset = 0h]
Figure 2-1070. Register 12Ah
7 6 5 4 3 2 1 0
MACRO_RESULT_REG12[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
