Serial Interface Register Maps
2.8.129 Register 120h (offset = 120h) [reset = 0h]
Figure 2-1060. Register 120h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG10[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1068. Register 120 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG10[7:0]
R 0h
Macro result register # 10. Interpretation of the contents of this
register depend on the last macro command
2.8.130 Register 121h (offset = 121h) [reset = 0h]
Figure 2-1061. Register 121h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG10[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1069. Register 121 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG10[15:8]
R 0h
Macro result register # 10. Interpretation of the contents of this
register depend on the last macro command
2.8.131 Register 122h (offset = 122h) [reset = 0h]
Figure 2-1062. Register 122h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG10[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1070. Register 122 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG10[23:16]
R 0h
Macro result register # 10. Interpretation of the contents of this
register depend on the last macro command
2.8.132 Register 123h (offset = 123h) [reset = 0h]
Figure 2-1063. Register 123h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG10[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
