Serial Interface Register Maps
2.7.10 Register 115h (offset = 115h) [reset = 2h]
Figure 2-931. Register 115h
7 6 5 4 3 2 1 0
0 0 0 0 0 CTL_OUTDIV_DIV_FB
R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-2h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-938. Register 115 Field Descriptions
Bit Field Type Reset Description
7-3 0 R/W 0h Must read or write 0
2-0
CTL_OUTDIV_DIV
_FB
R/W 2h
