Serial Interface Register Maps
2.13.436 Register 5E4h (offset = 5E4h) [reset = 0h]
Figure 2-1848. Register 5E4h
7 6 5 4 3 2 1 0
RX_AGC_MAX_ATTN_USED
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1861. Register 5E4 Field Descriptions
Bit Field Type Reset Description
5-0
RX_AGC_MAX_AT
TN_USED
R 0h
Max attenuation seen by stat module. This is in 0.5 dB
resolution.
2.13.437 Register 5E5h (offset = 5E5h) [reset = 0h]
Figure 2-1849. Register 5E5h
7 6 5 4 3 2 1 0
RX_AGC_MIN_ATTN_USED
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1862. Register 5E5 Field Descriptions
Bit Field Type Reset Description
5-0
RX_AGC_MIN_AT
TN_USED
R 0h
Min attenuation seen by stat module. This is in 0.5 dB
resolution.
2.13.438 Register 5E6h (offset = 5E6h) [reset = 0h]
Figure 2-1850. Register 5E6h
7 6 5 4 3 2 1 0
RX_AGC_MAX_DVGA_ATTN_USED
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1863. Register 5E6 Field Descriptions
Bit Field Type Reset Description
5-0
RX_AGC_MAX_DV
GA_ATTN_USED
R 0h
Max dvga attn seen by stat module. This is in 0.5 dB
resolution.
2.13.439 Register 5E7h (offset = 5E7h) [reset = 0h]
Figure 2-1851. Register 5E7h
7 6 5 4 3 2 1 0
RX_AGC_MIN_DVGA_ATTN_USED
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
