Serial Interface Register Maps
2.8.94 Register FDh (offset = FDh) [reset = 0h]
Figure 2-1025. Register FDh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG1[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1033. Register FD Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG1[15:8]
R 0h
Macro result register # 1. Interpretation of the contents of this
register depend on the last macro command
2.8.95 Register FEh (offset = FEh) [reset = 0h]
Figure 2-1026. Register FEh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG1[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1034. Register FE Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG1[23:16]
R 0h
Macro result register # 1. Interpretation of the contents of this
register depend on the last macro command
2.8.96 Register FFh (offset = FFh) [reset = 0h]
Figure 2-1027. Register FFh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG1[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1035. Register FF Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG1[31:24]
R 0h
Macro result register # 1. Interpretation of the contents of this
register depend on the last macro command
2.8.97 Register 100h (offset = 100h) [reset = 0h]
Figure 2-1028. Register 100h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG2[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
