Serial Interface Register Maps
2.8.115 Register 112h (offset = 112h) [reset = 0h]
Figure 2-1046. Register 112h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG6[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1054. Register 112 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG6[23:16]
R 0h
Macro result register # 6. Interpretation of the contents of this
register depend on the last macro command
2.8.116 Register 113h (offset = 113h) [reset = 0h]
Figure 2-1047. Register 113h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG6[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1055. Register 113 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG6[31:24]
R 0h
Macro result register # 6. Interpretation of the contents of this
register depend on the last macro command
2.8.117 Register 114h (offset = 114h) [reset = 0h]
Figure 2-1048. Register 114h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG7[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1056. Register 114 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG7[7:0]
R 0h
Macro result register # 7. Interpretation of the contents of this
register depend on the last macro command
2.8.118 Register 115h (offset = 115h) [reset = 0h]
Figure 2-1049. Register 115h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG7[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
