Table 1-14. (continued)
Macro TX Interface Rate Configuration
1 0x00 1 Validity TX Interface Rate
Validity
Bit 0: 1 → Value
specified in operand
2 is valid for 1TX
Bit 1: 1 → Value
specified in operand
2 is valid for 2TX
Bit 2: 1→ Value
specified in operand
2 is valid for 3TX
Bit 3: 1 → Value
specified in operand
2 is valid for 4TX
Bits 7:4:
RESERVED
2 0x01 1 Index TX Interface rate
index for above
mask. Mapping from
index to actual rate
is given below.
(x = 61.44 MHz)
0 → RESERVED
1 → RESERVED
2 → 2x = 122.88
MHz
3 → 3x = 184.32
MHz
4 → 4x = 245.76
MHz
5 → 6x = 368.64
MHz
6 → 8x = 491.52
MHz
7 → 12x = 737.28
MHz
8 → 16x = 983.04
MHz
9 → 24x = 1474.56
MHz
10 → 32x = 1966.08
MHz
11 → 48x = 2949.12
MHz
>11 → RESERVED
Memory Not used
1.2.1.7.1 Error Reporting
Table 1-15 lists the error conditions associated with this macro.
Table 1-15.
Error Status Registers Interpretation
Error Code 1 (16-bit)
Bit[0]: ‘1’ → Invalid TX Interface Rate Validity argument
Bit[1]: ‘1’ → Invalid Interface Rate Index argument
Error Code 2 (32-bit) Not Used
1.2.1.8 RX ADC Rate configuration
This macro specifies the Analog-to-Digital Converter (ADC) sampling rate(s) to be used for the RX
channel(s). The supported rates are listed below. Note that the ratio of ADC rates of the 2 sides (RX12
and RX34) can only be 1:1, 1:2 or 2:1.
