IO Wrap Register Map
1211
SBAU337May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.16.641 Register 140Ah (offset = 140Ah) [reset = 0h]
Figure 2-2904. Register 140Ah
7 6 5 4 3 2 1 0
READ_INTPO_
RXB_PKDET_3
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2920. Register 140A Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
B_PKDET_3
R 0h read only register for function intpo_rxb_pkdet_3
2.16.642 Register 140Bh (offset = 140Bh) [reset = 0h]
Figure 2-2905. Register 140Bh
7 6 5 4 3 2 1 0
READ_INTPO_
RXC_PKDET_0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2921. Register 140B Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
C_PKDET_0
R 0h read only register for function intpo_rxc_pkdet_0
2.16.643 Register 140Ch (offset = 140Ch) [reset = 0h]
Figure 2-2906. Register 140Ch
7 6 5 4 3 2 1 0
READ_INTPO_
RXC_PKDET_1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2922. Register 140C Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
C_PKDET_1
R 0h read only register for function intpo_rxc_pkdet_1
2.16.644 Register 140Dh (offset = 140Dh) [reset = 0h]
Figure 2-2907. Register 140Dh
7 6 5 4 3 2 1 0
READ_INTPO_
RXC_PKDET_2
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
