Serial Interface Register Maps
2.12.186 Register 588h (offset = 588h) [reset = 0h]
Figure 2-1389. Register 588h
7 6 5 4 3 2 1 0
TX_IP_PAP_E
N_PAP_BAND
1
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1401. Register 588 Field Descriptions
Bit Field Type Reset Description
0-0
TX_IP_PAP_EN_P
AP_BAND1
R/W 0h
TX-JESD interface, PAP dual and single band mode control
0:dual band
1:single band
0 : dual band
1 : single band
2.12.187 Register 589h (offset = 589h) [reset = 0h]
Figure 2-1390. Register 589h
7 6 5 4 3 2 1 0
TX_IP_PAP_DET_ALARM_CLR
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1402. Register 589 Field Descriptions
Bit Field Type Reset Description
2-0
TX_IP_PAP_DET_
ALARM_CLR
R/W 0h
TX-JESD interface PAP detection alarm clear. Value 1 = clear,
0 = noclear
bit [0] = Moving average mode
bit [1] = High pass filter mode
bit [2] = Reserved
2.12.188 Register 58Ah (offset = 58Ah) [reset = 0h]
Figure 2-1391. Register 58Ah
7 6 5 4 3 2 1 0
TX_IP_PAP_DET_ALARM_MASK
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1403. Register 58A Field Descriptions
Bit Field Type Reset Description
2-0
TX_IP_PAP_DET_
ALARM_MASK
R/W 0h
TX-JESD interface PAP detection alarm Mask. Value 1 =
mask, 0 = nomask.
bit [0] = Moving average mode
bit [1] = High pass filter mode
bit [2] = Reserved
