Serial Interface Register Maps
2.16.667 Register 1457h (offset = 1457h) [reset = 0h]
Figure 2-2930. Register 1457h
7 6 5 4 3 2 1 0
READ_INTPO_
FBCD_PKDET
_2
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2946. Register 1457 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_FB
CD_PKDET_2
R 0h read only register for function intpo_fbcd_pkdet_2
2.16.668 Register 1458h (offset = 1458h) [reset = 0h]
Figure 2-2931. Register 1458h
7 6 5 4 3 2 1 0
READ_INTPO_
FBCD_PKDET
_3
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2947. Register 1458 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_FB
CD_PKDET_3
R 0h read only register for function intpo_fbcd_pkdet_3
2.16.669 Register 17D0h (offset = 17D0h) [reset = 0h]
Figure 2-2932. Register 17D0h
7 6 5 4 3 2 1 0
READ_INTPI_S
PIB2_CS_N
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2948. Register 17D0 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_SPIB
2_CS_N
R 0h read only register for function intpi_spib2_cs_n
