Texas Instruments AFE79 Series User Manual

IO Wrap Register Map www.ti.com
1188
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.16.571 Register 1009h (offset = 1009h) [reset = 2h]
Figure 2-2834. Register 1009h
7 6 5 4 3 2 1 0
OVR_SEL_INT
PO_SPIB2_SD
O
OVR_INTPO_S
PIB2_SDO
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2850. Register 1009 Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPO_
SPIB2_SDO
R/W 1h
control to select whether the input function intpo_spib2_sdo
needs to be overriden ot not. 1 indicates override.
0-0
OVR_INTPO_SPIB
2_SDO
R/W 0h
override value for intpo_spib2_sdo when
ovr_sel_intpo_spib2_sdo is made high
2.16.572 Register 106Ch (offset = 106Ch) [reset = 0h]
Figure 2-2835. Register 106Ch
7 6 5 4 3 2 1 0
POL_INTPO_R
XA_PKDET_0
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2851. Register 106C Field Descriptions
Bit Field Type Reset Description
0-0
POL_INTPO_RXA_
PKDET_0
R/W 0h
polarity control for intpo_rxa_pkdet_0. 0 indicates pass
through from GPIO when selected 1 indicates inverted signal
2.16.573 Register 106Dh (offset = 106Dh) [reset = 2h]
Figure 2-2836. Register 106Dh
7 6 5 4 3 2 1 0
OVR_SEL_INT
PO_RXA_PKD
ET_0
OVR_INTPO_R
XA_PKDET_0
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2852. Register 106D Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPO_
RXA_PKDET_0
R/W 1h
control to select whether the input function intpo_rxa_pkdet_0
needs to be overriden ot not. 1 indicates override.
0-0
OVR_INTPO_RXA
_PKDET_0
R/W 0h
override value for intpo_rxa_pkdet_0 when
ovr_sel_intpo_rxa_pkdet_0 is made high
