Serial Interface Register Maps
2.16.55 Register 248h (offset = 248h) [reset = 1h]
Figure 2-2318. Register 248h
7 6 5 4 3 2 1 0
PULL_CTRL_GPIO_18
R/W-1h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2334. Register 248 Field Descriptions
Bit Field Type Reset Description
2-0
PULL_CTRL_GPIO
_18
R/W 1h
Bit 0 indicates Pull up enable.
Bit <1> Indicates Pull value.
Bit <2> is unused.
2.16.56 Register 249h (offset = 249h) [reset = 2h]
Figure 2-2319. Register 249h
7 6 5 4 3 2 1 0
IBUF_ST_GPIO_18
R/W-2h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2335. Register 249 Field Descriptions
Bit Field Type Reset Description
1-0
IBUF_ST_GPIO_1
8
R/W 2h Input buffer signal strength
2.16.57 Register 24Ah (offset = 24Ah) [reset = 0h]
Figure 2-2320. Register 24Ah
7 6 5 4 3 2 1 0
ODRIV_DS_GPIO_18
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2336. Register 24A Field Descriptions
Bit Field Type Reset Description
1-0
ODRIV_DS_GPIO_
18
R/W 0h output buffer drive strength.
2.16.58 Register 24Ch (offset = 24Ch) [reset = 1h]
Figure 2-2321. Register 24Ch
7 6 5 4 3 2 1 0
PULL_CTRL_GPIO_19
R/W-1h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
