Serial Interface Register Maps
2.16.716 Register 1807h (offset = 1807h) [reset = 0h]
Figure 2-2979. Register 1807h
7 6 5 4 3 2 1 0
READ_INTPI_
RXA_ALC_INP
UT_2_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2995. Register 1807 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXA
_ALC_INPUT_2_B
0
R 0h read only register for function intpi_rxa_alc_input_2_b0
2.16.717 Register 1808h (offset = 1808h) [reset = 0h]
Figure 2-2980. Register 1808h
7 6 5 4 3 2 1 0
READ_INTPI_
RXB_ALC_INP
UT_0_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2996. Register 1808 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXB
_ALC_INPUT_0_B
0
R 0h read only register for function intpi_rxb_alc_input_0_b0
2.16.718 Register 1809h (offset = 1809h) [reset = 0h]
Figure 2-2981. Register 1809h
7 6 5 4 3 2 1 0
READ_INTPI_
RXB_ALC_INP
UT_1_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2997. Register 1809 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXB
_ALC_INPUT_1_B
0
R 0h read only register for function intpi_rxb_alc_input_1_b0
