Serial Interface Register Maps
2.16.762 Register 1839h (offset = 1839h) [reset = 0h]
Figure 2-3025. Register 1839h
7 6 5 4 3 2 1 0
READ_INTPI_
RXC_ALC_INP
UT_3_B1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3041. Register 1839 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXC
_ALC_INPUT_3_B
1
R 0h read only register for function intpi_rxc_alc_input_3_b1
2.16.763 Register 183Ah (offset = 183Ah) [reset = 0h]
Figure 2-3026. Register 183Ah
7 6 5 4 3 2 1 0
READ_INTPI_
RXD_ALC_INP
UT_3_B1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3042. Register 183A Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXD
_ALC_INPUT_3_B
1
R 0h read only register for function intpi_rxd_alc_input_3_b1
2.16.764 Register 183Bh (offset = 183Bh) [reset = 0h]
Figure 2-3027. Register 183Bh
7 6 5 4 3 2 1 0
READ_INTPI_F
BAB_ALC_INP
UT_0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3043. Register 183B Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_FBA
B_ALC_INPUT_0
R 0h read only register for function intpi_fbab_alc_input_0
