Serial Interface Register Maps
Table 2-2206. Register 642 Field Descriptions
Bit Field Type Reset Description
5-0
FB_ALC_INPUT_D
ELAY_CODE
R/W 8h
Delay in number of clock cycles of fs/4 used to de-skew the
ALC input to counter skew
2.14.310 Register 644h (offset = 644h) [reset = 0h]
Figure 2-2193. Register 644h
7 6 5 4 3 2 1 0
FB_ALC_EXP_
OFFSET_INPU
T_ALC_FORC
E
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2207. Register 644 Field Descriptions
Bit Field Type Reset Description
0-0
FB_ALC_EXP_OF
FSET_INPUT_ALC
_FORCE
R/W 0h
Used in Input ALC mode
0 : Automatic computation
1 : Use the force value for exponent
2.14.311 Register 645h (offset = 645h) [reset = 0h]
Figure 2-2194. Register 645h
7 6 5 4 3 2 1 0
FB_ALC_EXP_OFFSET_INPUT_ALC_FORCE_VAL
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2208. Register 645 Field Descriptions
Bit Field Type Reset Description
4-0
FB_ALC_EXP_OF
FSET_INPUT_ALC
_FORCE_VAL
R/W 0h
2.14.312 Register 648h (offset = 648h) [reset = 0h]
Figure 2-2195. Register 648h
7 6 5 4 3 2 1 0
FB_ALC_MIN_ATTN_DSA
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2209. Register 648 Field Descriptions
Bit Field Type Reset Description
5-0
FB_ALC_MIN_ATT
N_DSA
R/W 0h
DSA min attenuation. DGC will compensate for gain changes
over and above this value only. 0.5 dB step size
