Macro
Table 1-56. (continued)
Macro TX Attenuation Update Trigger
5 0x06 2 Attenuation A2 Attenuation value
(in steps of 0.125
dB) for Band1 of the
second TX in the
selected TX side
(e.g. if TX Side
Select is 0, this
corresponds to
2TX). E.g. field
value of 10 implies
1.25 dB attenuation.
Attenuation > 39 dB
is NOT allowed.
6 0x08 2 Attenuation A3 Attenuation value
(in steps of 0.125
dB) for Band2 of the
second TX in the
selected TX side
(e.g. if TX Side
Select is 0, this
corresponds to
2TX). E.g. field
value of 10 implies
1.25 dB attenuation.
Attenuation > 39 dB
is NOT allowed.
Memory Not Used
1.2.4.1.1 Error Reporting
Following table lists the error conditions associated with this macro.
Table 1-57.
Error Status Registers Interpretation
Error Code 1 (16-bit) 0 → NO_ERROR
1 → INVALID_TX_SEL
2 → INVALID_ATTN_VALIDITY
3 → INVALID_ATTN_VALUE
Error Code 2 (32-bit) Not Used
1.2.5 RX AUTOMATIC GAIN CONTROL (AGC)
1.2.5.1 AGC Digital Detector Configuration
Table 1-58.
Macro AGC Digital Detector Configuration Macro
Opcode 0x58
Operand Offset Length Value Functionality Results
