Serial Interface Register Maps
2.8.108 Register 10Bh (offset = 10Bh) [reset = 0h]
Figure 2-1039. Register 10Bh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG4[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1047. Register 10B Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG4[31:24]
R 0h
Macro result register # 4. Interpretation of the contents of this
register depend on the last macro command
2.8.109 Register 10Ch (offset = 10Ch) [reset = 0h]
Figure 2-1040. Register 10Ch
7 6 5 4 3 2 1 0
MACRO_RESULT_REG5[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1048. Register 10C Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG5[7:0]
R 0h
Macro result register # 5. Interpretation of the contents of this
register depend on the last macro command
2.8.110 Register 10Dh (offset = 10Dh) [reset = 0h]
Figure 2-1041. Register 10Dh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG5[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1049. Register 10D Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG5[15:8]
R 0h
Macro result register # 5. Interpretation of the contents of this
register depend on the last macro command
2.8.111 Register 10Eh (offset = 10Eh) [reset = 0h]
Figure 2-1042. Register 10Eh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG5[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
