Texas Instruments AFE79 Series - 2.8.112 Register 10 Fh (offset = 10 Fh) [reset = 0 h]; 2.8.113 Register 110 h (offset = 110 h) [reset = 0 h]; 2.8.114 Register 111 h (offset = 111 h) [reset = 0 h]

www.ti.com Macro Register Map
573
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-1050. Register 10E Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG5[23:16]
R 0h
Macro result register # 5. Interpretation of the contents of this
register depend on the last macro command
2.8.112 Register 10Fh (offset = 10Fh) [reset = 0h]
Figure 2-1043. Register 10Fh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG5[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1051. Register 10F Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG5[31:24]
R 0h
Macro result register # 5. Interpretation of the contents of this
register depend on the last macro command
2.8.113 Register 110h (offset = 110h) [reset = 0h]
Figure 2-1044. Register 110h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG6[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1052. Register 110 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG6[7:0]
R 0h
Macro result register # 6. Interpretation of the contents of this
register depend on the last macro command
2.8.114 Register 111h (offset = 111h) [reset = 0h]
Figure 2-1045. Register 111h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG6[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1053. Register 111 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG6[15:8]
R 0h
Macro result register # 6. Interpretation of the contents of this
register depend on the last macro command
