2.16.790 Register 1855h (offset = 1855h) [reset = 0h]
Figure 2-3053. Register 1855h
7 6 5 4 3 2 1 0
READ_INTPI_T
X_GAIN_SW_2
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3069. Register 1855 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_TX_
GAIN_SW_2
R 0h read only register for function intpi_tx_gain_sw_2
2.16.791 Register 1856h (offset = 1856h) [reset = 0h]
Figure 2-3054. Register 1856h
7 6 5 4 3 2 1 0
READ_INTPI_T
X_GAIN_SW_3
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3070. Register 1856 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_TX_
GAIN_SW_3
R 0h read only register for function intpi_tx_gain_sw_3
2.16.792 Register 1857h (offset = 1857h) [reset = 0h]
Figure 2-3055. Register 1857h
7 6 5 4 3 2 1 0
READ_INTPI_F
B_NCOSEL_0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3071. Register 1857 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_FB_
NCOSEL_0
R 0h read only register for function intpi_fb_ncosel_0
2.16.793 Register 1858h (offset = 1858h) [reset = 0h]
Figure 2-3056. Register 1858h
7 6 5 4 3 2 1 0
READ_INTPI_F
B_NCOSEL_1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
