www.ti.com
SERDES Register Map
533
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.6.206 Register 7E1Fh (offset = 7E1Fh) [reset = 0h]
Figure 2-920. Register 7E1Fh
7 6 5 4 3 2 1 0
MCU_WRITE MCU_START CHKSUM_ERR
R/W-0h R/W-0h R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-926. Register 7E1F Field Descriptions
Bit Field Type Reset Description
7-7 MCU_WRITE R/W 0h
AHB sets this bit to '1' to initiate frame write. This bit will be
cleared by the MCU after the write is complete.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register. The entire register [15:0] holds the eye diagram data.
6-6 MCU_START R/W 0h
AHB sets this bit to '1' to tell MCU to start execution.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
5-5 CHKSUM_ERR R 0h
MCU sets this bit to indicate a checksum error has occurred.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.207 Register 7E20h (offset = 7E20h) [reset = 0h]
Figure 2-921. Register 7E20h
7 6 5 4 3 2 1 0
DUMMYPAGESELECT
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-927. Register 7E20 Field Descriptions
Bit Field Type Reset Description
3-0
DUMMYPAGESEL
ECT
R/W 0h dummy enables
