SERDES Register Map
www.ti.com
518
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-881. Register 7022 Field Descriptions
Bit Field Type Reset Description
3-3
CTLE_SEARCH_D
ISABLE_LN3
R/W 0h
1h Disable CTLE search for lane 3
0h Enable CTLE search for lane 3
2-2
CTLE_SEARCH_D
ISABLE_LN2
R/W 0h
1h Disable CTLE search for lane 2
0h Enable CTLE search for lane 2
1-1
CTLE_SEARCH_D
ISABLE_LN1
R/W 0h
1h Disable CTLE search for lane 1
0h Enable CTLE search for lane 1
0-0
CTLE_SEARCH_D
ISABLE_LN0
R/W 0h
1h Disable CTLE search for lane 0
0h Enable CTLE search for lane 0
2.6.162 Register 7028h (offset = 7028h) [reset = 0h]
Figure 2-876. Register 7028h
7 6 5 4 3 2 1 0
FIRMWARE_EXEC_CTRL[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-882. Register 7028 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_EXEC
_CTRL[7:0]
R/W 0h
Read:
0000h Firmware is not downloaded or running.
6A6Ah Firmware download was successful and execution has
started.
Write:
FFF0h To reload firmware, write this register to 0xFFF0 and
restart CPU by writing a value of 0xAAA and then 0x000 to
the DOMAIN_RESET field in register 980D.
2.6.163 Register 7029h (offset = 7029h) [reset = 0h]
Figure 2-877. Register 7029h
7 6 5 4 3 2 1 0
FIRMWARE_EXEC_CTRL[15:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-883. Register 7029 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_EXEC
_CTRL[15:8]
R/W 0h
Read:
0000h Firmware is not downloaded or running.
6A6Ah Firmware download was successful and execution has
started.
Write:
FFF0h To reload firmware, write this register to 0xFFF0 and
restart CPU by writing a value of 0xAAA and then 0x000 to
the DOMAIN_RESET field in register 980D.
