Macro
Table 1-10. (continued)
Macro RX Interface Rate Configuration
1 0x00 1 Validity RX Interface Rate
Validity
Bit 0: 1 → Value
specified in operand
2 is valid for 1RX
Bit 1: 1 → Value
specified in operand
2 is valid for 2RX
Bit 2: 1 → Value
specified in operand
2 is valid for 3RX
Bit 3: 1 → Value
specified in operand
2 is valid for 4RX
Bits 7:4:
RESERVED
2 0x01 1 Index RX Interface rate for
selected channels.
Mapping from index
to actual rate is
given below
(x = 61.44 MHz)
0 → 1x = 61.44
MHz
1 → 1.5x = 92.16
MHz
2 → 2x = 122.88
MHz
3 → 3x = 184.32
MHz
4 → 4x = 245.76
MHz
5 → 6x = 368.64
MHz
6 → 8x = 491.52
MHz
7 → 12x = 737.28
MHz
8 → 16x = 983.04
MHz
9 → 24x = 1474.56
MHz
>9 → RESERVED
Memory Not used
1.2.1.5.1 Error Reporting
Table 1-11 lists the error conditions associated with this macro.
Table 1-11.
Error Status Registers Interpretation
Error Code 1 (16-bit)
Bit[0]: ‘1’ → Invalid RX Interface Rate Validity argument
Bit[1]: ‘1’ → Invalid Interface Rate Index argument
Error Code 2 (32-bit) Not Used
1.2.1.6 FB Interface Rate Configuration
This macro specifies the interface rate(s) for FB channel(s). A total of 8 interface rates are supported as
tabulated below. For a given FB Channel ADC rate, only a specific subset of interface rates is supported.
