Serial Interface Register Maps
2.16.577 Register 1075h (offset = 1075h) [reset = 2h]
Figure 2-2840. Register 1075h
7 6 5 4 3 2 1 0
OVR_SEL_INT
PO_RXA_PKD
ET_2
OVR_INTPO_R
XA_PKDET_2
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2856. Register 1075 Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPO_
RXA_PKDET_2
R/W 1h
control to select whether the input function intpo_rxa_pkdet_2
needs to be overriden ot not. 1 indicates override.
0-0
OVR_INTPO_RXA
_PKDET_2
R/W 0h
override value for intpo_rxa_pkdet_2 when
ovr_sel_intpo_rxa_pkdet_2 is made high
2.16.578 Register 1078h (offset = 1078h) [reset = 0h]
Figure 2-2841. Register 1078h
7 6 5 4 3 2 1 0
POL_INTPO_R
XA_PKDET_3
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2857. Register 1078 Field Descriptions
Bit Field Type Reset Description
0-0
POL_INTPO_RXA_
PKDET_3
R/W 0h
polarity control for intpo_rxa_pkdet_3. 0 indicates pass
through from GPIO when selected 1 indicates inverted signal
2.16.579 Register 1079h (offset = 1079h) [reset = 2h]
Figure 2-2842. Register 1079h
7 6 5 4 3 2 1 0
OVR_SEL_INT
PO_RXA_PKD
ET_3
OVR_INTPO_R
XA_PKDET_3
R/W-1h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2858. Register 1079 Field Descriptions
Bit Field Type Reset Description
1-1
OVR_SEL_INTPO_
RXA_PKDET_3
R/W 1h
control to select whether the input function intpo_rxa_pkdet_3
needs to be overriden ot not. 1 indicates override.
0-0
OVR_INTPO_RXA
_PKDET_3
R/W 0h
override value for intpo_rxa_pkdet_3 when
ovr_sel_intpo_rxa_pkdet_3 is made high
