Serial Interface Register Maps
2.6.194 Register 7E13h (offset = 7E13h) [reset = 0h]
Figure 2-908. Register 7E13h
7 6 5 4 3 2 1 0
FIRMWARE_DATA9[15:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-914. Register 7E13 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
9[15:8]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.195 Register 7E14h (offset = 7E14h) [reset = 0h]
Figure 2-909. Register 7E14h
7 6 5 4 3 2 1 0
FIRMWARE_DATAA[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-915. Register 7E14 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
A[7:0]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.196 Register 7E15h (offset = 7E15h) [reset = 0h]
Figure 2-910. Register 7E15h
7 6 5 4 3 2 1 0
FIRMWARE_DATAA[15:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-916. Register 7E15 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
A[15:8]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
