2.16.759 Register 1836h (offset = 1836h) [reset = 0h]
Figure 2-3022. Register 1836h
7 6 5 4 3 2 1 0
READ_INTPI_
RXD_ALC_INP
UT_2_B1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3038. Register 1836 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXD
_ALC_INPUT_2_B
1
R 0h read only register for function intpi_rxd_alc_input_2_b1
2.16.760 Register 1837h (offset = 1837h) [reset = 0h]
Figure 2-3023. Register 1837h
7 6 5 4 3 2 1 0
READ_INTPI_
RXA_ALC_INP
UT_3_B1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3039. Register 1837 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXA
_ALC_INPUT_3_B
1
R 0h read only register for function intpi_rxa_alc_input_3_b1
2.16.761 Register 1838h (offset = 1838h) [reset = 0h]
Figure 2-3024. Register 1838h
7 6 5 4 3 2 1 0
READ_INTPI_
RXB_ALC_INP
UT_3_B1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3040. Register 1838 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXB
_ALC_INPUT_3_B
1
R 0h read only register for function intpi_rxb_alc_input_3_b1
