Macro TX Channel Frequency set
2 0x01 1 Num NCOs Number of NCOs
per band
Bit 0: number of
NCOs in band 0
0 → Single NCO
1 → Dual NCO
Bit 1: number of
NCOs in band 1
0 → Single NCO
1 → Dual NCO
3 0x02 4 Frequency Value TX Channel
frequency for NCO
1, Band 1 in
specified resolution.
In case of 1 kHz
resolution mode,
value of up to TX-
DAC-RATE is only
allowed.
4 0x06 4 Frequency Value TX Channel
frequency for NCO
1, Band 2 in
specified resolution.
In case of 1 kHz
resolution mode,
value of up to TX-
DAC-RATE is only
allowed.
5 0x0A 4 Frequency Value TX Channel
frequency for NCO
2, Band 1 in
specified resolution.
In case of 1 kHz
resolution mode,
value of up to TX-
DAC-RATE is only
allowed.
6 0x0E 4 Frequency Value TX Channel
frequency for NCO
2, Band 2 in
specified resolution
In case of 1-kHz
resolution mode,
value of up to TX-
DAC-RATE is only
allowed.
Memory Not used
1.2.1.12.1 Error Reporting
Table 1-25 lists the error conditions associated with this macro.
Table 1-25.
Error Status Registers Interpretation
Error Code 1 (16-bit)
Bit[0]: ‘1’ → Invalid TX Channel Frequency Validity argument.
Bit[1]: ‘1’ → Invalid Num-NCOs argument.
Bit[2]: ‘1’ → Invalid first Frequency Value argument.
Bit[3]: ‘1’ → Invalid second Frequency Value argument.
Bit[4]: ‘1’ → Invalid third Frequency Value argument.
Bit[5]: ‘1’ → Invalid fourth Frequency Value argument.
Error Code 2 (32-bit) Not Used
