Page #1084 background image
IO Wrap Register Map
www.ti.com
1084
SBAU337May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-2562. Register 454 Field Descriptions (continued)
Bit Field Type Reset Description
1-0
BUF_DIR_CTRL_G
PIO_21
R/W 1h
Controls the direction of GPIO
0 both input and output are not selected.. can be used for
analog
1 input mode
2 output mode
3 shouldnt be used
2.16.284 Register 457h (offset = 457h) [reset = 0h]
Figure 2-2547. Register 457h
7 6 5 4 3 2 1 0
ACTIV_BIR_DIR_CTRL_GPIO_21 reserved
R/W-0h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2563. Register 457 Field Descriptions
Bit Field Type Reset Description
3-1
ACTIV_BIR_DIR_C
TRL_GPIO_21
R/W 0h
Control to indicate whether the GPIO_21 needs dynamic
ouptu t enabling.
0 to 3 --> Static direction
4 --> Use the IO for 3 pin SPI B2 SDIO.
5 --> Use the IO for 4 pin SPI B2 SDO
6 --> Use the IO for 3 pin SPI B1 SDIO.
7 --> use the IO for 4 pin SPI B1 SDO.
0-0 reserved R/W 0h
2.16.285 Register 458h (offset = 458h) [reset = 1h]
Figure 2-2548. Register 458h
7 6 5 4 3 2 1 0
reserved reserved BUF_DIR_CTRL_GPIO_22
R/W-0h R/W-0h R/W-1h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2564. Register 458 Field Descriptions
Bit Field Type Reset Description
7-5 reserved R/W 0h
4-2 reserved R/W 0h
1-0
BUF_DIR_CTRL_G
PIO_22
R/W 1h
Controls the direction of GPIO
0 both input and output are not selected.. can be used for
analog
1 input mode
2 output mode
3 shouldnt be used
