Serial Interface Register Maps
2.6.188 Register 7E0Dh (offset = 7E0Dh) [reset = 0h]
Figure 2-902. Register 7E0Dh
7 6 5 4 3 2 1 0
FIRMWARE_DATA6[15:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-908. Register 7E0D Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
6[15:8]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.189 Register 7E0Eh (offset = 7E0Eh) [reset = 0h]
Figure 2-903. Register 7E0Eh
7 6 5 4 3 2 1 0
FIRMWARE_DATA7[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-909. Register 7E0E Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
7[7:0]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.190 Register 7E0Fh (offset = 7E0Fh) [reset = 0h]
Figure 2-904. Register 7E0Fh
7 6 5 4 3 2 1 0
FIRMWARE_DATA7[15:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-910. Register 7E0F Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
7[15:8]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
