Serial Interface Register Maps
2.8.122 Register 119h (offset = 119h) [reset = 0h]
Figure 2-1053. Register 119h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG8[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1061. Register 119 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG8[15:8]
R 0h
Macro result register # 8. Interpretation of the contents of this
register depend on the last macro command
2.8.123 Register 11Ah (offset = 11Ah) [reset = 0h]
Figure 2-1054. Register 11Ah
7 6 5 4 3 2 1 0
MACRO_RESULT_REG8[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1062. Register 11A Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG8[23:16]
R 0h
Macro result register # 8. Interpretation of the contents of this
register depend on the last macro command
2.8.124 Register 11Bh (offset = 11Bh) [reset = 0h]
Figure 2-1055. Register 11Bh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG8[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1063. Register 11B Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG8[31:24]
R 0h
Macro result register # 8. Interpretation of the contents of this
register depend on the last macro command
2.8.125 Register 11Ch (offset = 11Ch) [reset = 0h]
Figure 2-1056. Register 11Ch
7 6 5 4 3 2 1 0
MACRO_RESULT_REG9[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
