Serial Interface Register Maps
Table 2-3056. Register 1848 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_TDD
_EN_RXD
R 0h read only register for function intpi_tdd_en_rxd
2.16.778 Register 1849h (offset = 1849h) [reset = 0h]
Figure 2-3041. Register 1849h
7 6 5 4 3 2 1 0
READ_INTPI_
RX_GAIN_SW_
0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3057. Register 1849 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RX_
GAIN_SW_0
R 0h read only register for function intpi_rx_gain_sw_0
2.16.779 Register 184Ah (offset = 184Ah) [reset = 0h]
Figure 2-3042. Register 184Ah
7 6 5 4 3 2 1 0
READ_INTPI_
RX_GAIN_SW_
1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3058. Register 184A Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RX_
GAIN_SW_1
R 0h read only register for function intpi_rx_gain_sw_1
2.16.780 Register 184Bh (offset = 184Bh) [reset = 0h]
Figure 2-3043. Register 184Bh
7 6 5 4 3 2 1 0
READ_INTPI_
RX_GAIN_SW_
2
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3059. Register 184B Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RX_
GAIN_SW_2
R 0h read only register for function intpi_rx_gain_sw_2
