Serial Interface Register Maps
2.13.417 Register 5B5h (offset = 5B5h) [reset = 0h]
Figure 2-1829. Register 5B5h
7 6 5 4 3 2 1 0
RX_AGC_BAND1_LNA_PHASE
28[9:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1842. Register 5B5 Field Descriptions
Bit Field Type Reset Description
1-0
RX_AGC_BAND1_
LNA_PHASE28[9:8
]
R/W 0h
LNA Phase for Band1 for temp index 28 in case of External
LNA Control , Phase for DVGA Index 60 in case of External
DVGA control
2.13.418 Register 5B6h (offset = 5B6h) [reset = 0h]
Figure 2-1830. Register 5B6h
7 6 5 4 3 2 1 0
RX_AGC_BAND1_LNA_PHASE29[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1843. Register 5B6 Field Descriptions
Bit Field Type Reset Description
7-0
RX_AGC_BAND1_
LNA_PHASE29[7:0
]
R/W 0h
LNA Phase for Band1 for temp index 29 in case of External
LNA Control , Phase for DVGA Index 61 in case of External
DVGA control
2.13.419 Register 5B7h (offset = 5B7h) [reset = 0h]
Figure 2-1831. Register 5B7h
7 6 5 4 3 2 1 0
RX_AGC_BAND1_LNA_PHASE
29[9:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1844. Register 5B7 Field Descriptions
Bit Field Type Reset Description
1-0
RX_AGC_BAND1_
LNA_PHASE29[9:8
]
R/W 0h
LNA Phase for Band1 for temp index 29 in case of External
LNA Control , Phase for DVGA Index 61 in case of External
DVGA control
2.13.420 Register 5B8h (offset = 5B8h) [reset = 0h]
Figure 2-1832. Register 5B8h
7 6 5 4 3 2 1 0
RX_AGC_BAND1_LNA_PHASE30[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
