Serial Interface Register Maps
2.16.784 Register 184Fh (offset = 184Fh) [reset = 0h]
Figure 2-3047. Register 184Fh
7 6 5 4 3 2 1 0
READ_INTPI_
GPIO_PKDET_
WIN_RXC
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3063. Register 184F Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_GPI
O_PKDET_WIN_R
XC
R 0h read only register for function intpi_gpio_pkdet_win_rxc
2.16.785 Register 1850h (offset = 1850h) [reset = 0h]
Figure 2-3048. Register 1850h
7 6 5 4 3 2 1 0
READ_INTPI_
GPIO_PKDET_
WIN_RXD
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3064. Register 1850 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_GPI
O_PKDET_WIN_R
XD
R 0h read only register for function intpi_gpio_pkdet_win_rxd
2.16.786 Register 1851h (offset = 1851h) [reset = 0h]
Figure 2-3049. Register 1851h
7 6 5 4 3 2 1 0
READ_INTPI_
GPIO_PKDET_
WIN_FBAB
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3065. Register 1851 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_GPI
O_PKDET_WIN_F
BAB
R 0h read only register for function intpi_gpio_pkdet_win_fbab
