TX Top Register Map www.ti.com
690
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-1393. Register 57D Field Descriptions
Bit Field Type Reset Description
3-0
TX_IP_PAP_HPF_
WINDOW_COUNT
ER[11:8]
R/W 0h
In the interface rate or Tx input (IP) PA Protection high pass
filter module, when the high pass filter output average
exceeds a thershold error hit is generated. The PA protection
can be triggered when the number of such hits in a
programmable window exceeds the count threshold. The
moving average count threshold can be programmed in the
range 0 to 2^12-1. The error accumulation counter is
programmable with value in the range 1 to 2^12-1. The error
counter threshold is programmed in the register
tx_ip_pap_hpf_error_threshold
2.12.179 Register 57Eh (offset = 57Eh) [reset = 0h]
Figure 2-1382. Register 57Eh
7 6 5 4 3 2 1 0
TX_IP_PAP_HPF_ERROR_THRESHOLD[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1394. Register 57E Field Descriptions
Bit Field Type Reset Description
7-0
TX_IP_PAP_HPF_
ERROR_THRESH
OLD[7:0]
R/W 0h
In the interface rate or Tx input (IP) PA Protection high pass
filter module, when the high pass filter output average
exceeds a thershold error hit is generated. The PA protection
can be triggered when the number of such hits in a
programmable window exceeds the count threshold. The
moving average count threshold can be programmed in the
range 0 to 2^12-1. The error accumulation counter is
programmable with value in the range 1 to 2^12-1. The error
window counter is programmed in the register
tx_ip_pap_hpf_window_counter
2.12.180 Register 57Fh (offset = 57Fh) [reset = 0h]
Figure 2-1383. Register 57Fh
7 6 5 4 3 2 1 0
TX_IP_PAP_HPF_ERROR_THRESHOLD[11:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1395. Register 57F Field Descriptions
Bit Field Type Reset Description
3-0
TX_IP_PAP_HPF_
ERROR_THRESH
OLD[11:8]
R/W 0h
In the interface rate or Tx input (IP) PA Protection high pass
filter module, when the high pass filter output average
exceeds a thershold error hit is generated. The PA protection
can be triggered when the number of such hits in a
programmable window exceeds the count threshold. The
moving average count threshold can be programmed in the
range 0 to 2^12-1. The error accumulation counter is
programmable with value in the range 1 to 2^12-1. The error
window counter is programmed in the register
tx_ip_pap_hpf_window_counter
